10B124E, V-Belt Pulley

10B124E, QD10A12.2/B12

Product Details for 10B124E

Comparable to: QD10A12.2/B12.4, 10B124.E, 10B12.4, 12.4-10B-E, B1240/10E, 10BQ124

Click to Enlarge

10B124E, V-Belt Pulley, Cast Iron

Specifications

Product Number 10B124E
Material Cast Iron
Bore Type QD
Outside Diameter (in) 12.750
Face Width (in) 7.750
Min. Bore (in) 0.875
Bushing E
Max. Bore (in) 3.500
MOQ 1
Weight (lb) 64.00
Part Number Cross Reference QD10A12.2/B12.4, 10B124.E, 10B12.4, 12.4-10B-E, B1240/10E, 10BQ124
Grooves 10
Set Screw Quantity 0
