11XL037-6A2, Timing Pulley

11XL037-6A2

Click to Enlarge

11XL037-6A2, Timing Pulley, Aluminum, Clear Anodized

Learn more about 11XL037-6A2 Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number	11XL037-6A2
Teeth	11
Tooth Style	XL
For Belt Width (in)	0.3750
Type	6
Material	Aluminum
Finish	Clear Anodized
Bore Type	Finished Bore
Bore (in)	0.188
Bore Description	3/16 Inch Finished Bore
Pitch Diameter (in)	0.700
Outside Diameter (in)	0.680
Flange Diameter (in)	0.938
Face Width (in)	0.563
Overall Length (in)	0.812
Hub Diameter (in)	0.500
Min. Bore (in)	0.1875
Unit System	Inch
P.D. (mm)	18.00
O.D. (mm)	17.30
MOQ	1
Weight (lb)	0.02
Part Number Cross Reference	A 6A3-11NF03706, A6A3-11NF03706, 11XL037 X 3/16 6A, PT011D06L06N, 11XL037-2A X 3/16, 11XL037-6A2, 11XL037-6A2
Set Screw Quantity	1
