12-3M06MIA5, Timing Pulley

12-3M06MIA5 - E-Z Lock Hub Aluminum Powerhouse®HTD® Pulleys

12-3M06MIA5

Click to Enlarge

12-3M06MIA5, Timing Pulley, Aluminum, Clear Anodized

Learn more about 12-3M06MIA5 Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number 12-3M06MIA5
Teeth 12
Tooth Style HTD3mm
For Belt Width (mm) 6.00
Type 6CI
Material Aluminum
Finish Clear Anodized
Bore Type EZ Lock
Bore Description 5 mm Finished Bore
Bore (mm) 5.00
Pitch Diameter (in) 0.451
Outside Diameter (in) 0.421
Face Width (in) 0.327
Unit System Metric
P.D. (mm) 12.00
O.D. (mm) 10.70
Flange Diameter (mm) 14.70
Overall Length (mm) 14.50
Hub Diameter (mm) 14.70
Number & Screw Size 1 x M2
MOQ 1
Weight (lb) 0.02
Part Number Cross Reference 12-3M06MIA5, 12-3M06MIA5
Set Screw Quantity 1
