12-5M09M6A6, Timing Pulley

12-5M09M6A6

Click to Enlarge

12-5M09M6A6, Timing Pulley, Aluminum, Clear Anodized

Learn more about 12-5M09M6A6 Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number	12-5M09M6A6
Teeth	12
Tooth Style	HTD5mm
For Belt Width (mm)	9.00
Type	6
Material	Aluminum
Finish	Clear Anodized
Bore Type	Finished Bore
Bore Description	6 mm Finished Bore
Bore (mm)	6.00
Pitch Diameter (in)	0.752
Outside Diameter (in)	0.707
Face Width (in)	0.547
Pulley Belt Width (mm)	9.00
Unit System	Metric
P.D. (mm)	19.00
O.D. (mm)	18.00
Face Width (mm)	13.90
Overall Length (mm)	20.20
Hub Diameter (mm)	11.10
MOQ	1
Weight (lb)	0.04
Part Number Cross Reference	A 6A25M012NF0906, A6A25M012NF0906, 12-5M09M6A6, 12-5M09M6A6
Set Screw Quantity	1
