12-5M15M6A6, Timing Pulley

12-5M15M6A6 - Aluminum Powerhouse®HTD® Pulleys

12-5M15M6A6

Click to Enlarge

12-5M15M6A6, Timing Pulley, Aluminum, Clear Anodized

Learn more about 12-5M15M6A6 Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number 12-5M15M6A6
Teeth 12
Tooth Style HTD5mm
For Belt Width (mm) 15.00
Type 6
Material Aluminum
Finish Clear Anodized
Bore Type Finished Bore
Bore Description 6 mm Finished Bore
Bore (mm) 6.00
Pitch Diameter (in) 0.752
Outside Diameter (in) 0.707
Face Width (in) 0.781
Pulley Belt Width (mm) 15.00
Unit System Metric
P.D. (mm) 19.00
O.D. (mm) 18.00
Face Width (mm) 19.80
Overall Length (mm) 26.20
Hub Diameter (mm) 11.10
MOQ 1
Weight (lb) 0.05
Part Number Cross Reference A 6A25M012NF1506, A6A25M012NF1506, 12-5M15M6A6, 12-5M15M6A6
Set Screw Quantity 1
