120LP075 Imperial Pitch Pulleys

120LP075

Product Details for 120LP075

120LP075, Timing Pulley, Teeth;120 | Pitch;L | For Belt Width;0.75 inch | Configuration;Split Taper Hub and No Flanges | Bored for Bushing Size;P1 | Material; Grey Iron

Specifications

Product Number 120LP075
Teeth 120
Tooth Style L
For Belt Width (in) 0.750
Type 13
Material Grey Iron
Bore Type Split Taper
Bore (in) P1
Pitch Diameter (in) 14.324
Outside Diameter (in) 14.294
Face Width (in) 1.000
Overall Length (in) 2.188
Unit System Inch
Bushing P1
Weight (lb) 11.40
List Price (1-9 Qty.) (USD) $180.00
Discount Price (10-24 Qty.) (USD) $160.00
Discount Price (25-49 Qty.) (USD) $140.00

Documentation

General Characteristics gen_char.html
Pulley Tolerances pulley_tol.html
Part Number Nomenclature Chart part_number_explain.pdf
Keyway Standards and Tolerances keyway_specs.pdf
Drive Alignment Guide proper alignment.pdf
For custom parts click here custom.html
