14-5M09-6A3, Timing Pulley

14-5M09-6A3 - Aluminum Powerhouse®HTD® Pulleys

Product Details for 14-5M09-6A3

Comparable to: A 6A25-014NF0908, A6A25-014NF0908, PT014G08L09N

Click to Enlarge

14-5M09-6A3, Timing Pulley, Aluminum, Clear Anodized

Learn more about 14-5M09-6A3 Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number 14-5M09-6A3
Teeth 14
Tooth Style HTD 5mm
For Belt Width (mm) 9
Type 6
Material Aluminum
Finish Clear Anodized
Bore Type Finished Bore
Bore (in) 1/4 Inch Finished Bore
Pitch Diameter (in) 0.877
Outside Diameter (in) 0.832
Face Width (in) 0.547
Overall Length (in) 0.796
Hub Diameter (in) 0.500
Min. Bore (in) 0.250
Unit System Inch
MOQ 1
Weight (lb) 0.05
Part Number Cross Reference A 6A25-014NF0908, A6A25-014NF0908, PT014G08L09N
Set Screw Quantity 2
