15-5M15M6A6, Timing Pulley

15-5M15M6A6 - Aluminum Powerhouse®HTD® Pulleys

Product Details for 15-5M15M6A6

Comparable to: A 6A25M015NF1506, A6A25M015NF1506

Click to Enlarge

15-5M15M6A6, Timing Pulley, Aluminum, Clear Anodized

Learn more about 15-5M15M6A6 Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number 15-5M15M6A6
Teeth 15
Tooth Style HTD 5mm
For Belt Width (mm) 15
Type 6
Material Aluminum
Finish Clear Anodized
Bore Type Finished Bore
Bore (mm) 6.00
Face Width (in) 0.781
Pulley Belt Width (mm) 15.00
Unit System Metric
P.D. (mm) 23.80
O.D. (mm) 22.70
Face Width (mm) 19.80
Overall Length (mm) 26.20
Hub Diameter (mm) 14.30
MOQ 1
Weight (lb) 0.06
Part Number Cross Reference A 6A25M015NF1506, A6A25M015NF1506
Set Screw Quantity 2
