18-3M06-6A3, Timing Pulley

18-3M06-6A3 - Aluminum Powerhouse®HTD® Pulleys

Product Details for 18-3M06-6A3

Comparable to: A 6A23-018NF0608, A6A23-018NF0608

Click to Enlarge

18-3M06-6A3, Timing Pulley, Aluminum, Clear Anodized

Learn more about 18-3M06-6A3 Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number 18-3M06-6A3
Teeth 18
Tooth Style HTD 3mm
For Belt Width (mm) 6
Type 6
Material Aluminum
Finish Clear Anodized
Bore Type Finished Bore
Bore (in) 1/4 Inch Finished Bore
Pitch Diameter (in) 0.677
Outside Diameter (in) 0.647
Face Width (in) 0.386
Overall Length (in) 0.691
Hub Diameter (in) 0.442
Min. Bore (in) 0.250
Unit System Inch
MOQ 1
Weight (lb) 0.02
Part Number Cross Reference A 6A23-018NF0608, A6A23-018NF0608
Set Screw Quantity 2
