19-3M09M6A6, Timing Pulley

19-3M09M6A6

Click to Enlarge

19-3M09M6A6, Timing Pulley, Aluminum, Clear Anodized

Learn more about 19-3M09M6A6 Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number	19-3M09M6A6
Teeth	19
Tooth Style	HTD3mm
For Belt Width (mm)	9.00
Type	6
Material	Aluminum
Finish	Clear Anodized
Bore Type	Finished Bore
Bore Description	6 mm Finished Bore
Bore (mm)	6.00
Pitch Diameter (in)	0.714
Outside Diameter (in)	0.684
Pulley Belt Width (mm)	9.00
Unit System	Metric
P.D. (mm)	18.00
O.D. (mm)	17.40
Face Width (mm)	12.80
Overall Length (mm)	20.60
Hub Diameter (mm)	11.90
MOQ	1
Weight (lb)	0.02
Part Number Cross Reference	A 6A23M019NF0906, A6A23M019NF0906, 19-3M09M6A6, 19-3M09M6A6
Set Screw Quantity	2
