19-5M15-6A3 Powerhouse™ HTD® Pulleys

19-5M15-6A3, A 6A25-019NF1508, PT019G08L15N

Product Details for 19-5M15-6A3

Comparable to: 19-5M15-6A3, A 6A25-019NF1508, PT019G08L15N

19-5M15-6A3, Timing Pulley, Powerhouse HTD, 1/4 Inch Bore, Aluminum

Specifications

Product Number 19-5M15-6A3
Teeth 19
Tooth Style HTD 5mm
For Belt Width (mm) 15.000
Type 6
Material Aluminum
Finish Clear Anodized
Bore Type Finished Bore
Bore (in) 0.25
Pitch Diameter (in) 1.191
Outside Diameter (in) 1.146
Face Width (in) 0.781
Overall Length (in) 1.032
Hub Diameter (in) 0.750
Set Screw 2 x 8-32 @ 90°
Min. Bore (in) 0.25
Unit System Inch
Weight (lb) 0.10
List Price (1-9 Qty.) (USD) 10.51
Discount Price (10-24 Qty.) (USD) 9.98
Discount Price (25-49 Qty.) (USD) 8.14
Discount Price (50-99 Qty.) (USD) 6.3
Discount Price (100-249 Qty.) (USD) 5.78
Part Number Cross Reference 19-5M15-6A3, A 6A25-019NF1508, PT019G08L15N

Documentation

Download Catalog 2015_BBMAN_CATALOG_104.pdf
General Characteristics gen_char.html
Pulley Tolerances pulley_tol.html
Part Number Nomenclature Chart part_number_explain.pdf
Drive Alignment Guide proper alignment.pdf
For custom parts click here custom.html
REACH Certification 19-5M15-6A3_REACH_cert
RoHS Certification 19-5M15-6A3_RoHS_cert
