192-14P55-3535, Timing Pulley

192-14P55-3535 - Cast Iron Powerhouse® Pulleys

Product Details for 192-14P55-3535

Comparable to: P192-14MGT-55, 2763928, B19214M55TL

Click to Enlarge

192-14P55-3535, Timing Pulley, Cast Iron, Black Oxide

Learn more about 192-14P55-3535 Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number 192-14P55-3535
Teeth 192
Tooth Style 14P
For Belt Width (mm) 55
Type C3
Material Cast Iron
Finish Black Oxide
Bore Type TL
Bore (in) 3535
Pitch Diameter (in) 33.686
Outside Diameter (in) 33.576
Face Width (in) 2.750
Overall Length (in) 3.500
Min. Bore (in) 1.1875
Unit System Inch
Bushing 3535
MOQ 1
Weight (lb) 432.30
Part Number Cross Reference P192-14MGT-55, 2763928, B19214M55TL
