20LT187-6A3, Timing Pulley

20LT187-6A3 - Aluminum Imperial Pitch Pulleys

Product Details for 20LT187-6A3

Comparable to: A 6A6-20NF01808, A6A6-20NF01808, 24M187-2A X 3/16

Click to Enlarge

20LT187-6A3, Timing Pulley, Aluminum, Clear Anodized

Learn more about 20LT187-6A3 Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number 20LT187-6A3
Teeth 20
Tooth Style LT
For Belt Width (in) 0.1875
Type 6
Material Aluminum
Finish Clear Anodized
Bore Type Finished Bore
Bore (in) 1/4 Inch Finished Bore
Pitch Diameter (in) 0.520
Outside Diameter (in) 0.506
Face Width (in) 0.750
Overall Length (in) 0.436
Hub Diameter (in) 0.436
Min. Bore (in) 0.250
Unit System Inch
MOQ 1
Weight (lb) 0.02
Part Number Cross Reference A 6A6-20NF01808, A6A6-20NF01808, 24M187-2A X 3/16
Set Screw Quantity 2
