20MP012-6FA2, Timing Pulley

20MP012-6FA2

Click to Enlarge

20MP012-6FA2, Timing Pulley, Aluminum, Clear Anodized

Learn more about 20MP012-6FA2 Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number	20MP012-6FA2
Teeth	20
Tooth Style	MXL
For Belt Width (in)	0.1250
Type	6F
Material	Aluminum
Finish	Clear Anodized
Flange Material	Aluminum
Bore Type	Finished Bore
Bore (in)	0.188
Bore Description	3/16 Inch Finished Bore
Pitch Diameter (in)	0.509
Outside Diameter (in)	0.489
Flange Diameter (in)	0.685
Face Width (in)	0.260
Overall Length (in)	0.484
Hub Diameter (in)	0.364
Min. Bore (in)	0.1875
Pulley Belt Width (in)	0.160
Unit System	Inch
P.D. (mm)	13.00
O.D. (mm)	12.40
MOQ	1
Weight (lb)	0.01
Part Number Cross Reference	A 6N16-020DF1206, A6N16-020DF1206, PB20MXL012, 20MP-012-3/16-6FCA, PT020A06L02T, TP7A3W2-20, 20MP012-6FA2, 20MP012-6FA2
Set Screw Quantity	2
