20XL037-6A3, Timing Pulley

20XL037-6A3 - Aluminum Imperial Pitch Pulleys

20XL037-6A3

Click to Enlarge

20XL037-6A3, Timing Pulley, Aluminum, Clear Anodized,

Learn more about 20XL037-6A3 Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number 20XL037-6A3
Teeth 20
Tooth Style XL
For Belt Width (in) 0.3750
Type 6
Material Aluminum
Finish Clear Anodized
Bore Type Finished Bore
Bore (in) 0.250
Bore Description 1/4 Inch Finished Bore
Pitch Diameter (in) 1.273
Outside Diameter (in) 1.253
Face Width (in) 0.563
Overall Length (in) 0.937
Hub Diameter (in) 0.938
Min. Bore (in) 0.25
Unit System Inch
P.D. (mm) 32.00
O.D. (mm) 31.80
MOQ 1
Weight (lb) 0.09
Part Number Cross Reference A 6A3-20NF03708, A6A3-20NF03708, 20XL037 X 1/4 6A, PT020D08L06N, 20XL037-2A X 1/4, 20XL037-6A3, 20XL037-6A3
Set Screw Quantity 2

Comparable to: A 6A3-20NF03708, A6A3-20NF03708, 20XL037 X 1/4 6A, PT020D08L06N, 20XL037-2A X 1/4, 20XL037-6A3, 20XL037-6A3

Documentation

Download Catalog
General Characteristics
Pulley Tolerances
Part Number Nomenclature Chart
Drive Alignment Guide
