24XH400-6FS10, Timing Pulley

24XH400-6FS10

Click to Enlarge

24XH400-6FS10, Timing Pulley, Steel, Black Oxide,

Learn more about 24XH400-6FS10 Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number	24XH400-6FS10
Teeth	24
Tooth Style	XH
For Belt Width (in)	4.0000
Type	6F
Material	Steel
Finish	Black Oxide
Flange Material	Steel
Bore Type	Minimum Plain Bore
Bore (in)	1.000
Bore Description	1 Inch Minimum Plain Bore
Pitch Diameter (in)	6.685
Outside Diameter (in)	6.575
Flange Diameter (in)	7.250
Face Width (in)	4.688
Overall Length (in)	5.938
Hub Diameter (in)	5.250
Min. Bore (in)	1
Unit System	Inch
P.D. (mm)	170.00
O.D. (mm)	167.00
MOQ	1
Weight (lb)	43.99
Part Number Cross Reference	24XH400, 24XHB400, P24XH400, 24XH400-6FS10, 24XH400-6FS10
