25B40SS, Roller Chain Sprocket

25B40SS

Product Details for 25B40SS

Comparable to: A 6X 7-2540, A6X7-2540, 25B40SS

Click to Enlarge

25B40SS, Roller Chain Sprocket, Stainless Steel

Learn more about 25B40SS Roller Chain Sprockets and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number 25B40SS
Teeth 40
Tooth Style 25
Type B
Material Stainless Steel
Bore Type Minimum Plain Bore
Bore (in) 1/2 Inch Minimum Plain Bore
Pitch Diameter (in) 3.186
Outside Diameter (in) 3.327
Face Width (in) 0.110
Overall Length (in) 0.750
Hub Diameter (in) 2.000
Min. Bore (in) 0.500
Unit System Inch
MOQ 1
Weight (lb) 0.53
Part Number Cross Reference A 6X 7-2540, A6X7-2540, 25B40SS
