26-3P09MIA6 Powerhouse™ Pulleys

26-3P09MIA6, A 6D53M026DF0906

Product Details for 26-3P09MIA6

Comparable to: 26-3P09MIA6, A 6D53M026DF0906,

26-3P09MIA6, Timing Pulley, Powerhouse, 6 mm Bore, Aluminum, E-Z Lock Hub

Specifications

Product Number 26-3P09MIA6
Teeth 26
Tooth Style GT 3mm
For Belt Width (mm) 9.000
Type 6CI
Material Aluminum
Finish Clear Anodized
Bore Type Finished Bore
Bore (mm) 6.00
Unit System Metric
P.D. (mm) 24.80
O.D. (mm) 24.10
Flange Diameter (mm) 28.10
Face Width (mm) 12.90
Overall Length (mm) 20.70
Hub Diameter (mm) 19.10
Number & Screw Size 1 x M3
Weight (lb) 0.04
List Price (1-9 Qty.) (USD) 19.7315
Discount Price (10-24 Qty.) (USD) 19.2123
Discount Price (25-49 Qty.) (USD) 15.8175
Discount Price (50-99 Qty.) (USD) 11.367
Discount Price (100-249 Qty.) (USD) 10.062
Part Number Cross Reference 26-3P09MIA6, A 6D53M026DF0906,

Documentation

Download Catalog 2015_BBMAN_CATALOG_134.pdf
General Characteristics gen_char.html
Pulley Tolerances pulley_tol.html
Part Number Nomenclature Chart part_number_explain.pdf
Drive Alignment Guide proper alignment.pdf
For custom parts click here custom.html
REACH Certification 26-3P09MIA6_REACH_cert
RoHS Certification 26-3P09MIA6_RoHS_cert
