28H200-6FS10, Timing Pulley

28H200-6FS10 - Steel Imperial Pitch Pulleys

28H200-6FS10

Click to Enlarge

28H200-6FS10, Timing Pulley, Steel, Black Oxide,

Learn more about 28H200-6FS10 Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number 28H200-6FS10
Teeth 28
Tooth Style H
For Belt Width (in) 2.0000
Type 6F
Material Ductile Iron
Finish Black Oxide
Flange Material Steel
Bore Type Minimum Plain Bore
Bore (in) 1 Inch Minimum Plain Bore
Pitch Diameter (in) 4.456
Outside Diameter (in) 4.402
Flange Diameter (in) 4.687
Face Width (in) 2.344
Overall Length (in) 3.406
Hub Diameter (in) 3.500
Min. Bore (in) 1.000
Pulley Belt Width (in) 2.094
Unit System Inch
P.D. (mm) 113.00
O.D. (mm) 111.80
MOQ 1
Weight (lb) 11.01
Part Number Cross Reference 28HB200, 114363, 28H200MPB, P28H200, 28H200-6FS10
