2AK114H, V-Belt Pulley

2AK114H, 2AK114-QT, 20179518, 2MAL114

Product Details for 2AK114H

Comparable to: 2AK114H, 2AK114-QT, 20179518, 2AK114, 2MAL113, 2AK114QT

Click to Enlarge

2AK114H, V-Belt Pulley, Cast Iron

Learn more about 2AK114H V-Belt Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number 2AK114H
Type 3
Material Cast Iron
Bore Type QD
Bore (in) H
Outside Diameter (in) 11.250
Face Width (in) 1.375
Overall Length (in) 1.719
Min. Bore (in) 0.375
Unit System Inch
Bushing H
MOQ 1
Pitch Dia. "A" 11.000
Pitch Dia. "3L" 10.660
Sheave Type AK
For Belt Type 4L, 3L, or A
Weight (lb) 8.50
Part Number Cross Reference 2AK114H, 2AK114-QT, 20179518, 2AK114, 2MAL113, 2AK114QT
Grooves 2
