2B136SK, V-Belt Pulley

2B136SK

2B136SK, V-Belt Pulley, Cast Iron

Learn more about 2B136SK V-Belt Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number	2B136SK
Type	D-3
Material	Cast Iron
Bore Type	QD
Bore Description	Bored for SK Bushing
Outside Diameter (in)	13.950
Face Width (in)	1.750
Min. Bore (in)	0.5
Unit System	Inch
Bushing	SK
MOQ	1
Pitch Dia. "A"	13.200
Pitch Dia. "B"	13.600
Sheave Type	A-B Combination
For Belt Type	A or B
Weight (lb)	20.00
Part Number Cross Reference	QD2A13.2/B13.6, 2B136SK, 13.6-2B-SK, 20179005, 2B136-SK SHEAVE, 1362B, 2B136, 2B136SK, 455601, 2B136SK
Grooves	2
