35B40, Roller Chain Sprocket

35B40, 35EM-B-40A

Product Details for 35B40

Comparable to: 35B40, 35EM-B-40A

Click to Enlarge

35B40, Roller Chain Sprocket, Steel

Learn more about 35B40 Roller Chain Sprockets and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number 35B40
Teeth 40
Tooth Style 35
Type B
Material Steel
Bore Type Minimum Plain Bore
Bore (in) 5/8 Inch Minimum Plain Bore
Pitch Diameter (in) 4.780
Outside Diameter (in) 4.990
Face Width (in) 0.168
Overall Length (in) 1.000
Hub Diameter (in) 2.250
Min. Bore (in) 0.625
Unit System Inch
MOQ 1
Weight (lb) 1.62
Part Number Cross Reference 35B40, 35EM-B-40A
