36-3M06-6A3, Timing Pulley

36-3M06-6A3 - Aluminum Powerhouse®HTD® Pulleys

Product Details for 36-3M06-6A3

Comparable to: A 6A23-036NF0608, A6A23-036NF0608

Click to Enlarge

36-3M06-6A3, Timing Pulley, Aluminum, Clear Anodized,

Learn more about 36-3M06-6A3 Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number 36-3M06-6A3
Teeth 36
Tooth Style HTD 3mm
For Belt Width (mm) 6
Type 6
Material Aluminum
Finish Clear Anodized
Bore Type Finished Bore
Bore (in) 1/4 Inch Finished Bore
Pitch Diameter (in) 1.353
Outside Diameter (in) 1.323
Face Width (in) 0.407
Overall Length (in) 0.713
Hub Diameter (in) 1.000
Min. Bore (in) 0.250
Unit System Inch
MOQ 1
Weight (lb) 0.08
Part Number Cross Reference A 6A23-036NF0608, A6A23-036NF0608
Set Screw Quantity 2
