40-3P09-6A3, Timing Pulley

40-3P09-6A3 - Aluminum Powerhouse® Pulleys

40-3P09-6A3

Click to Enlarge

40-3P09-6A3, Timing Pulley, Aluminum, Clear Anodized,

Learn more about 40-3P09-6A3 Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number 40-3P09-6A3
Teeth 40
Tooth Style 3P
For Belt Width (mm) 9.00
Type 6
Material Aluminum
Finish Clear Anodized
Bore Type Finished Bore
Bore (in) 0.250
Bore Description 1/4 Inch Finished Bore
Pitch Diameter (in) 1.504
Outside Diameter (in) 1.474
Face Width (in) 0.527
Overall Length (in) 0.833
Hub Diameter (in) 1.150
Min. Bore (in) 0.25
Unit System Inch
P.D. (mm) 38.00
O.D. (mm) 37.40
MOQ 1
Weight (lb) 0.12
Part Number Cross Reference A 6A53-040NF0908, A6A53-040NF0908, 3MR-40S-09 6, 40-3P09-6A3, 40-3P09-6A3
Set Screw Quantity 2
