40A35

40A35, Roller Chain Sprocket

40A35

40A35, Roller Chain Sprocket, Steel

Learn more about 40A35 Roller Chain Sprockets and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number	40A35
Teeth	35
Tooth Style	40
Type	A
Material	Steel
Bore Type	Minimum Plain Bore
Bore (in)	0.625
Bore Description	5/8 Inch Minimum Plain Bore
Pitch Diameter (in)	5.578
Outside Diameter (in)	5.855
Overall Length (in)	0.284
Min. Bore (in)	0.625
Unit System	Inch
MOQ	1
Weight (lb)	1.70
Part Number Cross Reference	40A35, 40A35, 40A35, 40A35, 40A35
Number of Strands	1
Number of Hubs	1
