40B57 Minimum Plain Bore Sprockets

40B57

Product Details for 40B57

Comparable to: 40B57

40B57, Roller Chain Sprocket, 3/4 Inch Bore, Steel

Specifications

Product Number 40B57
Teeth 57
Tooth Style 40
Type B
Material Steel
Bore Type Minimum Plain Bore
Bore (in) 3/4 Inch Minimum Plain Bore
Pitch Diameter (in) 9.076
Outside Diameter (in) 9.363
Face Width (in) 0.284
Overall Length (in) 1.125
Hub Diameter (in) 3.500
Min. Bore (in) 0.75
Unit System Inch
Weight (lb) 6.74
Part Number Cross Reference 40B57

Documentation

Download Catalog 2015_BBMAN_CATALOG_339.pdf
For custom parts click here custom.html
REACH Certification 40B57_REACH_cert
RoHS Certification 40B57_RoHS_cert
