40L100-6FA6 Imperial Pitch Pulleys

40L100-6FA6

Product Details for 40L100-6FA6

Comparable to: 40L100-6FA6,

40L100-6FA6, Timing Pulley, Powerhouse Timing, 1/2 Inch Bore, Aluminum

Specifications

Product Number 40L100-6FA6
Teeth 40
Tooth Style L
For Belt Width (in) 1.000
Type 6F
Material Aluminum
Finish Clear Anodized
Flange Material Aluminum
Bore Type Finished Bore
Bore (in) 0.5
Pitch Diameter (in) 4.775
Outside Diameter (in) 4.745
Flange Diameter (in) 5.000
Face Width (in) 1.250
Overall Length (in) 1.750
Hub Diameter (in) 3.625
Set Screw 2 x 1/4-20 @ 90°
Min. Bore (in) 0.5
Unit System Inch
Weight (lb) 2.64
List Price (1-9 Qty.) (USD) 76
Discount Price (10-24 Qty.) (USD) 72.2
Discount Price (25-49 Qty.) (USD) 64.6
Discount Price (50-99 Qty.) (USD) 57
Discount Price (100-249 Qty.) (USD) 51.3
Part Number Cross Reference 40L100-6FA6,

Documentation

Download Catalog 2015_BBMAN_CATALOG_43.pdf
General Characteristics gen_char.html
Pulley Tolerances pulley_tol.html
Part Number Nomenclature Chart part_number_explain.pdf
Drive Alignment Guide proper alignment.pdf
For custom parts click here custom.html
REACH Certification 40L100-6FA6_REACH_cert
RoHS Certification 40L100-6FA6_RoHS_cert
