50XL037-6WA5 Imperial Pitch Pulleys

50XL037-6WA5

Product Details for 50XL037-6WA5

Comparable to: 50XL037-6WA5,

50XL037-6WA5, Timing Pulley, Powerhouse Timing, 3/8 Inch Bore, Aluminum

Specifications

Product Number 50XL037-6WA5
Teeth 50
Tooth Style XL
For Belt Width (in) 0.375
Type 6
Material Aluminum
Finish Clear Anodized
Flange Material Aluminum
Bore Type Finished Bore
Bore (in) 0.375
Pitch Diameter (in) 3.183
Outside Diameter (in) 3.163
Face Width (in) 0.563
Overall Length (in) 1.000
Hub Diameter (in) 1.500
Set Screw 2 x 10-32 @ 90°
Min. Bore (in) 0.563
Unit System Inch
Weight (lb) 0.38
List Price (1-9 Qty.) (USD) 24.07
Discount Price (10-24 Qty.) (USD) 22.87
Discount Price (25-49 Qty.) (USD) 19.26
Discount Price (50-99 Qty.) (USD) 16.85
Discount Price (100-249 Qty.) (USD) 15.65
Part Number Cross Reference 50XL037-6WA5,

Documentation

Download Catalog 2015_BBMAN_CATALOG_22.pdf
General Characteristics gen_char.html
Pulley Tolerances pulley_tol.html
Part Number Nomenclature Chart part_number_explain.pdf
Drive Alignment Guide proper alignment.pdf
For custom parts click here custom.html
REACH Certification 50XL037-6WA5_REACH_cert
RoHS Certification 50XL037-6WA5_RoHS_cert
