56-3M06M6A8, Timing Pulley

56-3M06M6A8 - Aluminum Powerhouse®HTD® Pulleys

Product Details for 56-3M06M6A8

Comparable to: A 6A23M056NF0608, A6A23M056NF0608

Click to Enlarge

56-3M06M6A8, Timing Pulley, Aluminum, Clear Anodized,

Learn more about 56-3M06M6A8 Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number 56-3M06M6A8
Teeth 56
Tooth Style HTD 3mm
For Belt Width (mm) 6
Type 6
Material Aluminum
Finish Clear Anodized
Bore Type Finished Bore
Bore (mm) 8.00
Pulley Belt Width (mm) 6.00
Unit System Metric
P.D. (mm) 53.50
O.D. (mm) 52.70
Face Width (mm) 10.30
Overall Length (mm) 18.60
Hub Diameter (mm) 31.80
MOQ 1
Weight (lb) 0.17
Part Number Cross Reference A 6A23M056NF0608, A6A23M056NF0608
Set Screw Quantity 2
