58V5300N, V-Belt Pulley

58V5300N

58V5300N, V-Belt Pulley, Cast Iron

B&B Manufacturing carries 58V5300N to accommodate the different industries we serve. Contact us today for a free quote!

Product Number	58V5300N
Type	C-3
Material	Cast Iron
Bore Type	QD
Bore Description	Bored for N Bushing
Pitch Diameter (in)	52.800
Outside Diameter (in)	53.000
Face Width (in)	6.000
Min. Bore (in)	2.4375
Unit System	Inch
Bushing	N
E (in)	1.125
L (in)	8.125
M (in)	1
MOQ	1
Sheave Type	8V
For Belt Type	8V
Weight (lb)	496.00
Part Number Cross Reference	QD5/8V53.00, 5 8V 5300 N, 8V53.0-5-N PULLEY, 20181022, 5-8V53.00-N SHEAVE, 8V3505, 58V53.0, 8V53.0-5-N, 5-8V53.00, 58V5300N, 455443, 58V5300N
Grooves	5
