60B13, Roller Chain Sprocket

60B13

60B13

60B13, Roller Chain Sprocket, Steel

Learn more about 60B13 Roller Chain Sprockets and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number 60B13
Teeth 13
Tooth Style 60
Type B
Material Steel
Bore Type Minimum Plain Bore
Bore Description 3/4 Inch Minimum Plain Bore
Pitch Diameter (in) 3.134
Outside Diameter (in) 3.493
Face Width (in) 0.459
Overall Length (in) 1.250
Hub Diameter (in) 2.344
Min. Bore (in) 0.75
Unit System Inch
MOQ 1
Weight (lb) 1.66
Part Number Cross Reference 60B13, 60B13, 60B13, 74395930, 60B13

Related Products

Comparable to: 60B13, 60B13, 60B13, 74395930, 60B13
