60B15, Roller Chain Sprocket

60B15

60B15

60B15, Roller Chain Sprocket, Steel

Learn more about 60B15 Roller Chain Sprockets and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number 60B15
Teeth 15
Tooth Style 60
Type B
Material Steel
Bore Type Minimum Plain Bore
Bore (in) 0.750
Bore Description 3/4 Inch Minimum Plain Bore
Pitch Diameter (in) 3.607
Outside Diameter (in) 3.978
Face Width (in) 0.459
Overall Length (in) 1.250
Hub Diameter (in) 2.875
Min. Bore (in) 0.750
Unit System Inch
MOQ 1
Weight (lb) 2.51
Part Number Cross Reference 60B15, 60B15, 60B15, 74395955, 60B15

Related Products

Comparable to: 60B15, 60B15, 60B15, 74395955, 60B15
