60B50, Roller Chain Sprocket

60B50

60B50

60B50, Roller Chain Sprocket, Steel

Learn more about 60B50 Roller Chain Sprockets and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number 60B50
Teeth 50
Tooth Style 60
Type B
Material Steel
Bore Type Minimum Plain Bore
Bore (in) 0.938
Bore Description 15/16 Inch Minimum Plain Bore
Pitch Diameter (in) 11.944
Outside Diameter (in) 12.371
Face Width (in) 0.459
Overall Length (in) 1.250
Hub Diameter (in) 4.250
Min. Bore (in) 0.9375
Unit System Inch
MOQ 1
Weight (lb) 15.82
Part Number Cross Reference 60B50, 60B50, 60B50, 60B50, 60B50, 60B50
Number of Strands 1
Number of Hubs 1
