85V1320F, V-Belt Pulley

85V1320F

85V1320F, V-Belt Pulley, Cast Iron

Learn more about 85V1320F V-Belt Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number	85V1320F
Type	A-3
Material	Cast Iron
Bore Type	QD
Bore Description	Bored for F Bushing
Pitch Diameter (in)	13.100
Outside Diameter (in)	13.200
Face Width (in)	5.813
Min. Bore (in)	1
Unit System	Inch
Bushing	F
E (in)	1.2187
L (in)	3.75
MOQ	1
Sheave Type	5V
For Belt Type	5V
Weight (lb)	80.00
Part Number Cross Reference	QD8/5V13.20, 8 5V 1320 F, 8-5V1320.F, 85V1320F, 5V13.2-8-F, 20180720, 8-5V13.20-F SHEAVE, 5V1328, 85V13.2, 5V13.2-8-F, 8/5V1320F, 8-5V13.20, 85V1320F, 8/5V1320F, 455405, 85V1320F
Grooves	8
