96LH075, Timing Pulley

96LH075 - Cast Iron Imperial Pitch Pulleys

96LH075

96LH075 - Cast Iron Imperial Pitch Pulleys Line Drawing

Click to Enlarge

96LH075, Timing Pulley, Cast Iron

Learn more about 96LH075 Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number 96LH075
Teeth 96
Tooth Style L
For Belt Width (in) 0.7500
Type 17
Material Cast Iron
Bore Type Split Taper
Bore Description Bored for H Bushing
Pitch Diameter (in) 11.459
Outside Diameter (in) 11.429
Face Width (in) 1.000
Overall Length (in) 1.500
Min. Bore (in) 0.375
Unit System Inch
Bushing H
P.D. (mm) 291.00
O.D. (mm) 290.30
MOQ 1
Weight (lb) 8.77
Part Number Cross Reference 96LH075, 96LH075, 96LH075
