F224-14MX20-F, Timing Pulley

F224-14MX20-F - Cast Iron Powerhouse® MX Pulleys

F224-14MX20-F

F224-14MX20-F - Cast Iron Powerhouse® MX Pulleys Line Drawing

Click to Enlarge

F224-14MX20-F, Timing Pulley, Cast Iron, Black Oxide

B&B Manufacturing carries F224-14MX20-F to accommodate the different industries we serve. Contact us today for a free quote!

Specifications

Product Number F224-14MX20-F
Teeth 224
Tooth Style 14MX
For Belt Width (mm) 20.00
Type C-3
Material Cast Iron
Finish Black Oxide
Bore Type QD
Bore Description Bored for F Bushing
Pitch Diameter (in) 39.300
Outside Diameter (in) 39.190
Face Width (in) 1.359
Overall Length (in) 3.000
Hub Diameter (in) 125.000
Min. Bore (in) 1
Unit System Inch
Bushing F
P.D. (mm) 998.00
O.D. (mm) 995.40
A (in) 35.625
B (in) 7.750
C (in) 1.360
D (in) 2.500
F (in) 1.36
M (in) 1.14
MOQ 1
Weight (lb) 138.00
Part Number Cross Reference F14M-224S-20, F14MX224S20-F, F14MX-224S-20 F FIN FAN, F14MX224S20-F, F224-14MX20-F, 482220, F224-14MX20-F
