QD48XH400, Timing Pulley

QD48XH400 - Cast Iron Imperial Pitch Pulleys

QD48XH400

QD48XH400 - Cast Iron Imperial Pitch Pulleys Line Drawing

Click to Enlarge

QD48XH400, Timing Pulley, Cast Iron, Black Oxide,

Learn more about QD48XH400 Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number QD48XH400
Teeth 48
Tooth Style XH
For Belt Width (in) 4.0000
Type D-2
Material Cast Iron
Finish Black Oxide
Bore Type QD
Bore Description Bored for J Bushing
Pitch Diameter (in) 13.369
Outside Diameter (in) 13.259
Face Width (in) 4.688
Overall Length (in) 5.438
Min. Bore (in) 1.5
Unit System Inch
Bushing J
P.D. (mm) 340.00
O.D. (mm) 336.80
MOQ 1
Weight (lb) 67.00
Part Number Cross Reference 48XH400J, 48XH400J, 48XH400-J, 20182114, 48XH400, 48XH400QD, 48XH400-J, P48XH400 J, 48XH400J, Q48XH400, QD48XH400, QD48XH400
