10B110E, V-Belt Pulley

10B110E, QD10A10.8/B11

10B110E

10B110E, V-Belt Pulley, Cast Iron

B&B Manufacturing carries 10B110E to accommodate the different industries we serve. Contact us today for a free quote!

Specifications

Product Number	10B110E
Type	A-3
Material	Cast Iron
Bore Type	QD
Bore Description	Bored for E Bushing
Outside Diameter (in)	11.350
Face Width (in)	7.750
Min. Bore (in)	0.875
Unit System	Inch
Bushing	E
MOQ	1
Pitch Dia. "A"	10.600
Pitch Dia. "B"	11.000
Sheave Type	A-B Combination
For Belt Type	A or B
Weight (lb)	56.00
Part Number Cross Reference	QD10B11.0, 10B110-E SHEAVE, 11010B, 10B110, 10B110E, 455765, 10B110E
Grooves	10

Related Products

Comparable to: QD10B11.0, 10B110-E SHEAVE, 11010B, 10B110, 10B110E, 455765, 10B110E
