128V4450P, V-Belt Pulley

128V4450P, QD12/8V44.

Product Details for 128V4450P

Comparable to: QD12/8V44.50, 12 8V 4450 P, 12-8V4450.P, 8V44.5-12-P PULLEY, 20181014, 12/8V44.5–P, 128V44.5, 8V44.5-12-P, 456686

Click to Enlarge

128V4450P, V-Belt Pulley, Cast Iron

B&B Manufacturing carries 128V4450P in various pitches to accommodate the different industries we serve. Contact us today for a free quote!

Specifications

Product Number 128V4450P
Material Cast Iron
Bore Type QD
Pitch Diameter (in) 44.300
Outside Diameter (in) 44.500
Face Width (in) 13.875
Min. Bore (in) 2.9375
Unit System Inch
Bushing P
E (in) 1/4
L (in) 9 3/8
M (in) 4 1/4
MOQ 1
Weight (lb) 825.00
Part Number Cross Reference QD12/8V44.50, 12 8V 4450 P, 12-8V4450.P, 8V44.5-12-P PULLEY, 20181014, 12/8V44.5–P, 128V44.5, 8V44.5-12-P, 456686
Grooves 12
Set Screw Quantity 0
