156HQ150, Timing Pulley

156HQ150 - Cast Iron Imperial Pitch Pulleys

156HQ150

156HQ150 - Cast Iron Imperial Pitch Pulleys Line Drawing

Click to Enlarge

156HQ150, Timing Pulley, Cast Iron

Learn more about 156HQ150 Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number 156HQ150
Teeth 156
Tooth Style H
For Belt Width (in) 1.5000
Type 13
Material Cast Iron
Bore Type Split Taper
Bore Description Bored for Q1 Bushing
Pitch Diameter (in) 24.828
Outside Diameter (in) 24.774
Face Width (in) 1.750
Overall Length (in) 2.781
Min. Bore (in) 0.75
Unit System Inch
Bushing Q1
P.D. (mm) 631.00
O.D. (mm) 629.30
MOQ 1
Weight (lb) 38.00
Part Number Cross Reference 156HQ150, 156HQ150, 156HQ150
