17-5M15-6A3, Timing Pulley

17-5M15-6A3 - Aluminum Powerhouse®HTD® Pulleys

Product Details for 17-5M15-6A3

Comparable to: A 6A25-017NF1508, A6A25-017NF1508, PT017G08L15N

Click to Enlarge

17-5M15-6A3, Timing Pulley, Aluminum, Clear Anodized

Learn more about 17-5M15-6A3 Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number 17-5M15-6A3
Teeth 17
Tooth Style HTD 5mm
For Belt Width (mm) 15
Type 6
Material Aluminum
Finish Clear Anodized
Bore Type Finished Bore
Bore (in) 1/4 Inch Finished Bore
Pitch Diameter (in) 1.065
Outside Diameter (in) 1.020
Face Width (in) 0.781
Overall Length (in) 1.032
Hub Diameter (in) 0.625
Min. Bore (in) 0.250
Unit System Inch
MOQ 1
Weight (lb) 0.08
Part Number Cross Reference A 6A25-017NF1508, A6A25-017NF1508, PT017G08L15N
Set Screw Quantity 2
