21LT312-6FA2 Imperial Pitch Pulleys

21LT312-6FA2, A 6A6-21DF03106, PT21C06L04T

Product Details for 21LT312-6FA2

Comparable to: 21LT312-6FA2, A 6A6-21DF03106, PT21C06L04T

21LT312-6FA2, Timing Pulley, Powerhouse Timing, 3/16 Inch Bore, Aluminum

Specifications

Product Number 21LT312-6FA2
Teeth 21
Tooth Style LT
For Belt Width (in) 0.313
Type 6F
Material Aluminum
Finish Clear Anodized
Flange Material Aluminum
Bore Type Finished Bore
Bore (in) 0.188
Pitch Diameter (in) 0.546
Outside Diameter (in) 0.532
Flange Diameter (in) 0.710
Face Width (in) 0.449
Overall Length (in) 0.688
Hub Diameter (in) 0.390
Set Screw 2 x 6-40 @ 90°
Min. Bore (in) 0.188
Pulley Belt Width (in) 0.350
Unit System Inch
Weight (lb) 0.02
List Price (1-9 Qty.) (USD) 10.12
Discount Price (10-24 Qty.) (USD) 9.61
Discount Price (25-49 Qty.) (USD) 7.84
Discount Price (50-99 Qty.) (USD) 5.82
Discount Price (100-249 Qty.) (USD) 5.06
Part Number Cross Reference 21LT312-6FA2, A 6A6-21DF03106, PT21C06L04T

Documentation

Download Catalog 2015_BBMAN_CATALOG_14.pdf
General Characteristics gen_char.html
Pulley Tolerances pulley_tol.html
Part Number Nomenclature Chart part_number_explain.pdf
Drive Alignment Guide proper alignment.pdf
For custom parts click here custom.html
REACH Certification 21LT312-6FA2_REACH_cert
RoHS Certification 21LT312-6FA2_RoHS_cert
