25B45SS, Roller Chain Sprocket

25B45SS

Product Details for 25B45SS

Comparable to: A 6X 7-2545, A6X7-2545, 25B45SS, 25B45

Click to Enlarge

25B45SS, Roller Chain Sprocket, Stainless Steel

Learn more about 25B45SS Roller Chain Sprockets and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number 25B45SS
Teeth 45
Tooth Style 25
Type B
Material Stainless Steel
Bore Type Minimum Plain Bore
Bore (in) 1/2 Inch Minimum Plain Bore
Pitch Diameter (in) 3.584
Outside Diameter (in) 3.725
Face Width (in) 0.110
Overall Length (in) 0.750
Hub Diameter (in) 2.000
Min. Bore (in) 0.500
Unit System Inch
MOQ 1
Weight (lb) 0.56
Part Number Cross Reference A 6X 7-2545, A6X7-2545, 25B45SS, 25B45
