• 28XL037-6A5

28XL037-6A5, Timing Pulley

28XL037-6A5

Buy Online

Download CAD View 3D Model Choose a CAD format

View Spec Sheet

Click to Enlarge

28XL037-6A5, Timing Pulley, Aluminum, Clear Anodized,

B&B Manufacturing carries 28XL037-6A5 to accommodate the different industries we serve. Contact us today for a free quote!

Specifications

Product Number	28XL037-6A5
Teeth	28
Tooth Style	XL
For Belt Width (in)	0.3750
Type	6
Material	Aluminum
Finish	Clear Anodized
Bore Type	Finished Bore
Bore (in)	0.375
Bore Description	3/8 Inch Finished Bore
Pitch Diameter (in)	1.783
Outside Diameter (in)	1.763
Face Width (in)	0.563
Overall Length (in)	0.937
Hub Diameter (in)	1.250
Min. Bore (in)	0.375
Unit System	Inch
P.D. (mm)	45.00
O.D. (mm)	44.80
MOQ	1
Weight (lb)	0.17
Part Number Cross Reference	28XL037-2A X 3/8, 28XL037-6A5, 28XL037-6A5
Set Screw Quantity	2

Comparable to: 28XL037-2A X 3/8, 28XL037-6A5, 28XL037-6A5
