2B380SF, V-Belt Pulley

2B380SF

2B380SF, V-Belt Pulley, Cast Iron

Learn more about 2B380SF V-Belt Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number	2B380SF
Type	D-3
Material	Cast Iron
Bore Type	QD
Bore Description	Bored for SF Bushing
Outside Diameter (in)	38.350
Face Width (in)	1.750
Min. Bore (in)	0.5
Unit System	Inch
Bushing	SF
MOQ	1
Pitch Dia. "A"	37.600
Pitch Dia. "B"	38.000
Sheave Type	A-B Combination
For Belt Type	A or B
Weight (lb)	64.00
Part Number Cross Reference	QD2A37.6/B38.0, 2B380SF, 38.0-2B-SF, 20179247, 2B380-SF SHEAVE, 3802B, 2B380, 2B380SF, 455608, 2B380SF
Grooves	2
