2B94SK, V-Belt Pulley

2B94SK

2B94SK, V-Belt Pulley, Cast Iron

Learn more about 2B94SK V-Belt Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number	2B94SK
Type	D-3
Material	Cast Iron
Bore Type	QD
Bore Description	Bored for SK Bushing
Outside Diameter (in)	9.750
Face Width (in)	1.750
Min. Bore (in)	0.5
Unit System	Inch
Bushing	SK
MOQ	1
Pitch Dia. "A"	9.000
Pitch Dia. "B"	9.400
Sheave Type	A-B Combination
For Belt Type	A or B
Weight (lb)	13.00
Part Number Cross Reference	QD2A9.0/B9.4, 2B94SK, 9.4-2B-SK, 20179499, 2B94-SK SHEAVE, 942B, 2B94, 2B94SK, 455598, 2B94SK
Grooves	2
