30-3M06-6A3, Timing Pulley

30-3M06-6A3 - Aluminum Powerhouse®HTD® Pulleys

Product Details for 30-3M06-6A3

Comparable to: A 6A23-030NF0608, A6A23-030NF0608

Click to Enlarge

30-3M06-6A3, Timing Pulley, Aluminum, Clear Anodized,

Learn more about 30-3M06-6A3 Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number 30-3M06-6A3
Teeth 30
Tooth Style HTD 3mm
For Belt Width (mm) 6
Type 6
Material Aluminum
Finish Clear Anodized
Bore Type Finished Bore
Bore (in) 1/4 Inch Finished Bore
Pitch Diameter (in) 1.128
Outside Diameter (in) 1.098
Face Width (in) 0.386
Overall Length (in) 0.691
Hub Diameter (in) 0.776
Min. Bore (in) 0.250
Unit System Inch
MOQ 1
Weight (lb) 0.05
Part Number Cross Reference A 6A23-030NF0608, A6A23-030NF0608
Set Screw Quantity 2
