44-3M09-6FA6, Timing Pulley

44-3M09-6FA6

Click to Enlarge

44-3M09-6FA6, Timing Pulley, Aluminum, Clear Anodized,

Learn more about 44-3M09-6FA6 Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number	44-3M09-6FA6
Teeth	44
Tooth Style	HTD3mm
For Belt Width (mm)	9.00
Type	6F
Material	Aluminum
Finish	Clear Anodized
Flange Material	Aluminum
Bore Type	Finished Bore
Bore (in)	0.500
Bore Description	1/2 Inch Finished Bore
Pitch Diameter (in)	1.654
Outside Diameter (in)	1.624
Flange Diameter (in)	1.775
Face Width (in)	0.833
Overall Length (in)	0.833
Hub Diameter (in)	1.300
Min. Bore (in)	0.5
Unit System	Inch
P.D. (mm)	42.00
O.D. (mm)	41.30
MOQ	1
Weight (lb)	0.14
Part Number Cross Reference	44-3M09-6FA6, 44-3M09-6FA6
Set Screw Quantity	2
