62-5M15M6A12, Timing Pulley

62-5M15M6A12 - Aluminum Powerhouse®HTD® Pulleys

Product Details for 62-5M15M6A12

Comparable to: A 6A25M062NF1512, A6A25M062NF1512

Click to Enlarge

62-5M15M6A12, Timing Pulley, Aluminum, Clear Anodized,

Learn more about 62-5M15M6A12 Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number 62-5M15M6A12
Teeth 62
Tooth Style HTD 5mm
For Belt Width (mm) 15
Type 6
Material Aluminum
Finish Clear Anodized
Bore Type Finished Bore
Bore (mm) 12.00
Pulley Belt Width (mm) 15.00
Unit System Metric
P.D. (mm) 98.70
O.D. (mm) 97.50
Face Width (mm) 19.80
Overall Length (mm) 30.10
Hub Diameter (mm) 38.10
MOQ 1
Weight (lb) 0.55
Part Number Cross Reference A 6A25M062NF1512, A6A25M062NF1512
Set Screw Quantity 2
