90XXHS200, Timing Pulley

90XXHS200 - Cast Iron Imperial Pitch Pulleys

90XXHS200

90XXHS200 - Cast Iron Imperial Pitch Pulleys Line Drawing

Click to Enlarge

90XXHS200, Timing Pulley, Cast Iron

Learn more about 90XXHS200 Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number 90XXHS200
Teeth 90
Tooth Style XXH
For Belt Width (in) 2.0000
Type 13
Material Cast Iron
Bore Type Split Taper
Bore Description Bored for S1 Bushing
Pitch Diameter (in) 35.810
Outside Diameter (in) 35.690
Face Width (in) 2.625
Overall Length (in) 4.750
Min. Bore (in) 1.5625
Unit System Inch
Bushing S1
P.D. (mm) 910.00
O.D. (mm) 906.50
MOQ 1
Weight (lb) 165.00
Part Number Cross Reference 90XXHS200, 90XXHS200, 90XXHS200
